The SFX-250VS is a reliable entry level PSU with 250 watts, which is totally enough for the everyday work. Thanks to the 80 mm Ultra Silent fan, the PSU is barely hearable.
Power
Total power: 250 W
AC input voltage: 230 V
AC input frequency: 50 Hz
Input current: 3 A
Power factor: 0.9
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 80 W
Combined power (+5V): 80 W
Combined power (-12V): 3.6 W
Combined power (+5Vsb): 15 W
Max output current (+3.3V): 14 A
Max output current (+12V1): 18.5 A
Max output current (+5V): 15 A
Max output current (-12V): 0.3 A
Max output current (+5Vsb): 3 A
Efficiency: 85%
Ports & interfaces
Motherboard power connector: 20+4 pin ATX
Number of SATA power connectors: 2
Peripheral (Molex) power connectors (4-pin): 2
Feature: ATX power connector (20+4 pin)
Floppy drive power connector: 1
Cabling type: Non-Modular
Performance
Purpose: PC
Power supply unit (PSU) form factor: SFX
ATX version: 2.3
Design
Product colour: Silver
Fan diameter: 8 cm
Number of fans: 1 fan(s)
Certificates
Certification: UVP; OVP; SCP; OPP; AFC;
Weight & dimensions
Width: 100 mm
Depth: 125 mm
Height: 64 mm
Chieftec SFX-250VS. Total power: 250 W, AC input voltage: 230 V, AC input frequency: 50 Hz. Motherboard power connector: 20+4 pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: SFX. Product colour: Silver, Fan diameter: 8 cm, Number of fans: 1 fan(s). Certification: UVP; OVP; SCP; OPP; AFC;
Chieftec
MBR CODE - SFX-250VS
EAN - 4710713239982
