ARCTIC’s versatile assortment of PC fans are both quiet and powerful. We have the right options for any application or need, in sizes from 80 to 140 mm. Plus, our case fans are equipped with state-of-the-art engine technology, innovative fan blades and high quality bearings, making them particularly durable and efficient.
Performance
Suitable location: Computer case
Type: Fan
Fan diameter: 14 cm
Rotational speed (min): 200 RPM
Rotational speed (max): 1700 RPM
Noise level: 0.3 sone
Maximum airflow: 72.8 cfm
Airflow: 123.69 m³/h
Maximum air pressure: 2.4 mmH2O
Feature: Pulse-width modulation (PWM) support
Bearing type: Fluid Dynamic Bearing (FDB)
Design
Product colour: White
Fan connector: 4-pin
Power
Voltage: 12 V
Starting voltage: 6 V
Rated current: 0.12 A
Weight & dimensions
Width: 140 mm
Depth: 140 mm
Height: 27 mm
Weight: 194 g
Cable length: 0.4 m
Package width: 143 mm
Package depth: 29 mm
Package height: 143 mm
Package weight: 230 g
Packaging content
Feature: Screws included
Number of screws: 4
Feature: Manual
Logistics data
Harmonized System (HS) code: 84733080
ARCTIC P14 PWM PST Pressure-optimised 140 mm Fan with PWM PST. Type: Fan, Fan diameter: 14 cm, Rotational speed (min): 200 RPM, Rotational speed (max): 1700 RPM, Noise level: 0.3 sone, Airflow: 123.69 m³/h, Maximum air pressure: 2.4 mmH2O, Bearing type: Fluid Dynamic Bearing (FDB). Voltage: 12 V. Width: 140 mm, Depth: 140 mm, Height: 27 mm. Product colour: White
ARCTIC
MBR CODE - ACFAN00197A
EAN - 4895213703116
